PRODUCT DESCRIPTION

Oval wire also called Hot dipped galvanized oval wire  , high resistance oval wire,  high resistance galvanized oval steel wire , alambre alta resistencia  is made from high quality steel wire by redrawn equipment. they are widely used in South America market.


Material

High carbon rod SAE1045,SAE1055,SAE1065 or low carbon Q195


Application

Mainly used for cattle frame to keep the cattle

Tensile Strength:600KGF-1550KGF



Packaging Detail

Plastic films inside and wove bag


Specification

Specification

Breaking
Force

Zinc
Coating

Diameter
Tolerance

Length

Weight

17/15

3.0*2.4mm

700kgf

Min.80g/m2

±0.06mm

1000M

45kg

16/14

2.7*2.2mm

600kgf

Min.80g/m2

±0.06mm

1250M

45kg

15/13

2.4*2.0mm

500kgf

Min.80g/m2

±0.06mm

1500M

45kg

14/12

2.2*1.8m

400kgf

Min.80g/m2

±0.06mm

1900M

45kg

N°1

2.4*2.8mm

500kgf

Min.80g/m2

±0.06mm

465M

25kg

N°6

4.55*5.25

500kgf

Min.80g/m2

±0.06mm

170M

25kg
